single facer

Specification:

Diameter of flute roller

Top roller    φ 340mm/360mm/408mm

Bottom roller  φ 320mm/360mm/408mm

Diameter of glue roller

Glue roller    φ 315mm

Doctor roller  φ160mm

Diameter of pressure roller

φ 180mm/320mm/360mm/410mm

Effective width

1800/2000/2200/2500mm

Mechanical Speed

200/min  230m/min  250m/min

Motor Power

37/44/55KW

Heat source

Steam

Product performance

Features:

1. Auto-controlling: The coder and PLC auto-controls according to change of speed.

2. Adjust advance and retreat of glue roll and pressure roll clearance: The electric motor drive cam micro-adjust, and display the adjusting quantity on inter-face by the displacement sensor.

3. With magic eye track set, break-paper detect system, glue roll and pressure roll automatic disengage when paper break.

4. Main drive with the separate gear box to shift drive, gear applies high qualified alloy to forge and grind with type of dip oil, low noise, long life.

5. Gap between lower corrugating roll and pressure roll, lower corrugating roll and glue roll, glue roll and doctor roll by electric mirco-adjustment and digital indication.

6. PLC auto glue mixing device to control the amount of glue effectively

7. Bearing imported from Japan of upper and lower corrugating roll and pressure roll with and high-temperature lubrication to keep running smooth and durable.
