Automatic Hot Foil Stamping & Die Cutting Machine

Features:

Automatic Hot Foil Stamping & Die Cutting Machine is used for carton box, label die-cutting, foil stamping and embossing especially on all kinds of exquisite printing materials such as the wine box, cigarette box, gift box, and the household appliance box, cosmetics box to achieve 3D and exquisite effect.


Product performance

Specification:

Model

MPK-1050AT

Max. sheet size

1050×750mm

Min. sheet size

400×360mm

Max. die cutting size

1040×720mm

Max. hot stamping size

1040×720mm

Gripper margin

9-17mm

Inner chase size

1080×745mm

Stock range

80-2000gsm(cardboard) ≤4mm (corrugated)

Die cutting accuracy

≤±0.1mm

Max. die cutting force

600T

Max. die cutting speed

7500s/h Die cutting

Max. feeder pile height

1600mm(wooden pallet included)

Max. delivery pile height

1400mm(wooden pallet included)

Max. gold foil diameter

250mm(vertical)

Electric-heated system

20 temperature ranges, 40-180℃ is adjustable

Foil width

20-1020mm

Main motor wattage

15kw

Overall dimension

7100×4260×2350mm

Net weight approx

20.5T

Full Load wattage

56kw
